FM22L16-55-TG IC
MPN:FM22L16-55TG // Ordering Information
#FM22L16-55-T#IC#Ramtron#現貨商#TRUSTBAND#EEROM#FRAM
| 4Mbit Ferroelectric Nonvolatile RAM |
| • Organized as 256Kx16 |
| • Configurable as 512Kx8 Using /UB, /LB |
| • 100 Trillion (1e14) Read/Write Cycles |
| • NoDelay™ Writes |
| • Page Mode Operation to 40MHz |
| • Advanced High-Reliability Ferroelectric Process |
| SRAM Compatible |
| • JEDEC 256Kx16 SRAM Pinout |
| • 55ns Access Time, 110ns Cycle Time |
| Advanced Features |
| • Low VDD Monitor Protects Memory against Inadvertent Writes |
| • Software Programmable Block Write Protect |
| Superior to Battery-backed SRAM Modules |
| • No Battery Concerns |
| • Monolithic Reliability |
| Low Power Operation |
| • 2.7V – 3.6V Power Supply |
| • Low Standby Current using /ZZ pin |
| • 12 mA Active Current |
| Industry Standard Configuration |
| • Industrial Temperature -40° C to +85° C |
| • 44-pin “Green”/RoHS TSOP-II Package |
| • True Surface Mount Solution, No Rework Steps |
| • Superior for Moisture, Shock, and Vibration |
| Ordering Information |
| • FM22L16-55-TG (55ns access, 44-pin "Green"/RoHS TSOP-II) |
| • FM22L16-55-TGTR (55ns access, 44-pin "Green"/RoHS TSOP-II, Tape & Reel) |
| If you have any inquiries, please don't hesitate to contact with Trustbond. |
-
